High Pressure Capacitive Pressure Sensor Differential Pressure Sensor


YUN YI ,we are professional manufacturer that engaged in the fields of pressure measurement instrument. Our company mainly produces pressure transmitter, ceamic pressure transmitter, temperature transmitter. flush disphragm pressure transmitter, smart digital pressure transmitter, wirelss pressure transmitter etc.



Description high pressure capacitive pressure sensor differential pressure sensor

3051 type smart 4-20ma differential pressure transmitter price is produced with proprietary technology, adopting imported silicon sensitive elements as well as normalized designed circuits and assembling technology to ensure product progressiveness, practical use, and quality stability. This 4-20ma pressure sensor may widely be used for all kinds of application.
High quality china 4-20ma Pressure sensor transmitter using use piezoresistive silicon oil-filled sensor as measurement component. china 4-20ma pressure sensor transmitter with isolated stainless steel diaphragm as signal sensing element, through automatic testing, laser trimming compensating zero and sensitivity in wider temperature range the amplifier circuit is in stainless steel housing, transforming sensor signal into standard output signal.



Images high pressure capacitive pressure sensor differential pressure sensor



High Pressure Capacitive Pressure Sensor Differential Pressure SensorHigh Pressure Capacitive Pressure Sensor Differential Pressure Sensor
High Pressure Capacitive Pressure Sensor Differential Pressure SensorHigh Pressure Capacitive Pressure Sensor Differential Pressure Sensor





Specification high pressure capacitive pressure sensor differential pressure sensor



Measure Range-100kPa~0.....10kPa...100MPa
Pressure Typegauge (G), absolute (A), sealed gauge (S)
Overpressure150%FS
Accuracy0.1%FS, 0.25%FS, 0.5%FS (optional)
Output signal4-20mA(2-wire), 0-5V;1-5V;0.5-4.5V;0-10V(3-wire)
Supply12-36Vdc,12~36Vdc;15~30Vdc;15~36Vdc;15~36Vdc;
Temp.coefficient of zero±0.02%FS/°C(typ.)            ±0.03%FS/°C(max.)
Temp.coefficient of span±0.02%FS/°C(typ.)            ±0.03%FS/°C(max.)
Compensated temperature range-10~+70°C
Operating temperature range-40~+125°C
Storage temperature range-40~+125°C
Insulating resistance≥100MΩ@100Vdc
Load resistanceR≤(U-15)/0.02 (for 4/20mA)       R>100kΩ(for voltage output)
Electrical interfaceDIN43650, option 1.5m cable connetion
Pressure interfaceG1/2,M20x1.5,G1/4, 1/4NPT, 1/2NPT(customer request)
Material of pressure membrane316L stainless steel
Material of housing1Cr18Ni9Ti stainless steel
Response time(10%~90%)≤10ms
Shock/impact10gRMS,(20~2000)Hz/100g,11ms
ProtectionIP65


Test High high pressure capacitive pressure sensor differential pressure sensor

 High Pressure Capacitive Pressure Sensor Differential Pressure Sensor




Applications high pressure capacitive pressure sensor differential pressure sensor

Petroleum industry, chemical industry, metallurgy industry, electric power, hydrology etc.
Boats&ships and aviation industry
Hydraulic pressure and pneumatic control system
