DS2 Series Full Wave Acoustic Emission Signal Analyzer
Our Advantage
- Continuous lost less waveform data storage collecting through all channels simultaneously, with no data missing.
- With waveform replay function, users can reset parameters such as the threshold, PDT, HDT and HLT, to get more accurate AE parameters to avoid the misleading by experience.
- Because of the continuous whole collection of AE signals, all acoustic emission location point has a corresponding waveform. You can get more precise location by adjusting the hitting time (manual or automatic).
- Any part of the waveform data can be exported to binary or txt file for MATLAB or other application.
Main Technical Specification
Type | DS2-A Series,DS2-B Series |
Channels | 2,4,6,8 channel |
Interface type | USB2.0 |
Operating system | Windows XP,win7(32bit) |
Data pass rate | Over 48MB/S |
Waveform data storage mode | Continuous lossless waveform data storage collecting through all channels simultaneously |
Continuous collecting duration | 5.8 hours(using 1TB harddisk) continuous lossless waveform data storage collecting through all 8 channels simultaneously by 3MHz sample rate |
A/D sampling accuracy | 16bit |
Sampling rate | 2-channels:10 MHz |
Waveform acquisition mode | Multi-channel simultaneous sampling |
Input voltage of signal | ±10V |
System noise level | ±0.308mV |
Channel input impedance | 50Ω |
A/D converter nonlinearity | ±0.5LSB |
Signal input type | Single-ended signal |
Trigger mode | Software trigger,the signal threshold trigger,external trigger |
External parameter channel | 8 channels (without DS2-A) |
External parameter sampling accuracy | 16bit (without DS2-A) |
External parameter input voltage of signal | ±5V/±10V (without DS2-A) |
Operating temperature range | 10ºC~50ºC |
Power mode | AC 220 |
