15 inch surface acoustic wave touchscreen monitor for POS machine
SAW Touch screen dust-proof touch monitor 1 touch point 1024*768 300cd vga/dvi / usb /rs232 plug
Product Specification
Advantage of SAW touch monitor:
· Industrial Desgin With Excellent Durablity
· SAW Technology 1 Touch Point
· High Light Transmission Clear Glass
· Easy to Use:Plug and Works on Windows/Linux/(Android)
· Perfect Solutions For Use In Public
· VESA Mounting and Rear Mounting
· 12 Months Warranty
· OEM/ODM& Customized Option: Brightness/Computer Integrated Inside, etc
· Factory Competitive Price & Fast Delivery
| General Information | |
| Model | COT150E-AWF02 |
| Series | Dust-proof open frame touch monitor |
| LCD Type | 15'' a-Si TFT-LCD |
| Video Input | VGA, DVI |
| OSD controls | Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset |
| Power Supply | Type: External brick Input (line) voltage: 100-240 VAC, 50-60 Hz Output voltage/current: 12 volts at 4 amps max |
| Mount Interface | 1)VESA 75mm and 100mm 2)Mount bracket, horizontal or vertical |
| LCD Specification | |
| Active Area(mm) | 304.128(H)×228.096(V) |
| Resolution | 1024×768@60Hz |
| Pixel Pitch(mm) | 0.297×0.297 |
| Nominal Input Voltage VDD | +3.3V(Typ) |
| Viewing angle (v/h) | 89°/89°/89°/89° |
| Contrast | 1500:1 |
| Luminance(cd/m2) | 300 |
| Response Time(Rising/Falling) | 20/15 (Typ.)(Tr/Td) ms |
| Support Color | 262K / 16.2Mcolors |
| Backlight MTBF(hr) | 50000 |
| Touchscreen Specification | |
| Type | CJTouch surface acoustic wave (SAW) touch screen |
| Touch Points | 1 touch point |
| Light Transmission | 92% |
| Touch Life Cycle | 50 millions |
| Touch Response time | 8ms |
| Touch System Interface | USB interface / RS232 |
| Power consumption | +5V@80mA |
| External AC Power Adapter | |
| Output | DC 12V /4A |
| Input | 100-240 VAC, 50-60 Hz |
| MTBF | 50000 hr at 25°C |
| Environment | |
| Operating Temp. | 0~50°C |
| Storage Temp. | -20~60°C |
| Operating RH: | 20%~80% |
| Storage RH: | 10%~90% |
Warranty & Components
1 Year Free Warranty for pos touchscreen monitor and all components.
USB Cable 120cm *1 Pcs,
VGA Cable 180cm *1 Pcs,
Power Cord with Switching Adapter *1 Pcs,
Bracket*2 Pcs
RS232 Cable & DVI Cable Sold Separately
Product Drawing
Product Application
Our pos touchscreen monitor are widely used in so many field, including transportation, entertainment, education, finance, industrial control, self service kiosk, etc.
Packaging & Shipping
1. Packing: 1pc pos touchscreen monitor /carton or 2pcs pos touchscreen monitors /carton, EPE inside
2. Shipping : Sample or small orders shipping by Fedex, UPS, DHL, TNT Door to Door, bulk orders by air / sea
About us
Dongguan CJTouch Electronic Co., Ltd. is a leading provider of Touchscreens, Touch monitors and All-in-one computers. With advanced, cost-effective touch solutions,CJTouch believes in engaging with customers while providing customized services.
Experience:
Established in 2006 and headquartered in Dongguan, China, CJTouch has proven to be reliable and trustworthy partners to help seamlessly integrate our products into your total solution.
Over 10 years of combined experience in researching and developing touch-enabled screens and monitors.
Two factories with over 200 skilled and qualified employees, including R & D engineers, technical experts and sales representatives.
What We Offer:
Through our consistent and high quality performance, CJTouch has got ISO 9001 certified and has earned CE, UL, FCC, RoHS and other international certifications.
Single & Multi-touch screens (custom sizes available)
Single & Multi-touch monitors (custom sizes and functions available)
All-in-one computers
ODM/OEM services
Technology:
CJTouch has always relied on continuous innovation to stay ahead in touch technology. We are committed to delivering the most cutting-edge solutions in the industry.
Surface Acoustic Wave (SAW) touch technology
Infrared touch technology
Projected Capacitive Touch technology
Applications:
We offer an extensive array of services with products being widely used in industries such as finance, gaming, retail, kiosk, health care, education, etc.
1. Production Line
Open Frame Touch Monitor
All-in-one Touch PC
2. Our factory
3. CJtouch families and Clients
4. Certifications
If you are interested in 15 inch surface acoustic wave touchscreen monitor for POS machine,pls contact us.
